evacuation systems:

Rock evacuation systems are designed for easy and safe evacuation of LPG cylinders before repair and for the evacuation of overfilled and leaking LPG cylinders.

• • Complete modular systems
  • All systems have extensively tested designs
  • Solutions for any evacuation requirement
  • Minimum cylinder handling
  • Means to prevent build-up of leaky and incorrectly filled cylinders
  • Ex-proof design for installation directly in the filling hall

 interests

•
  • Modular solutions with buffer tanks, pump, compressor and discharge racks
  • High level of safety due to rapid handling of leaky and incorrectly filled tubes
  • No bottleneck - total discharge system including pipes designed by Kaya
  • Different discharge heads mounted on the same discharge rack

Facilities:

• Manual or automatic operation
• Manual or automatic tilting independent discharge racks for industrial cylinders
• Fixed drain racks for 1 to 12 household cylinders
• Tiltable discharge racks for 4 to 8 domestic cylinders
• In-line or independent discharge racks for domestic cylinders
• Air driven compressor for small capacities
• Compressor/pump solutions for high capacities
• Discharge heads for center valves and screw valves

Working Safety:

• Ex marking according to the ATEX Directive and applicable EN standards: II 2G Ex h IIA T4 Gb CE logo EX logo
• All equipment and machinery in the filling system are designed to operate in hazardous areas classified as Zone 1 or Zone 2 according to EN/IEC 80079—36:2016.
• Gas evacuation system equipment is designed and certified according to a certified ISO:9001 quality management system; moreover, it is designed according to all relevant requirements set out in the applicable EU Directives.
